Name of product structure and material of cable

(1) the wire: the most basic essential main component products are current orelectromagnetic wave information transmission function.

Main material: the wires are electrically conductive wire core referred to, made by conductive properties of copper, aluminum, copper clad steel, copper clad aluminumand other non-ferrous metal with excellent, optical fiber as the wire.

A bare copper wire, tinned wire; single branch, strand; twisted tinning line.

(2) the insulating layer is coated components: plays a role in wire electrical insulationperiphery. That can ensure the transmission of current or electromagnetic waves,light waves travel along the wires and not only flow to the outside, the conductor has the potential (i.e. potential on the formation of the surrounding objects, namely thedifference voltage) can be isolated, i.e., both to ensure the normal transmission function of the wire, but also to ensure that the external object and personal safety.Conductor and the insulating layer is composed of cable products (except the bare wire) two basic components must have. Main material: PVC, PE, XLPE, PP, F,polypropylene fluorine plastics, rubber, paper, mica tape

(3) filling structure: a lot of wire and cable products are the multi core, these insulating wire core or lines on the cable (or packet multiple cable), a shape is not round, two is an insulating cable core has the very big space, and must join the filling structure in the cable, filling knot the structure is to make the displayport cable outer diameter relative roundin favor of bag, extrusion sheath. Main material: PP rope

(4): is a kind of shielding cable products in the field and outside electromagneticisolation components; cable products from different lines in its internal (or group) toalso need mutual isolation between. The shielding layer can be said to be an"electromagnetic screen". The conductor shielding of high voltage cables andinsulation shielding to electric field distribution homogenization. Main material: bare copper wire, copper clad steel wire, tinned copper wire

(5) layer of protection: when the electric wire and mini displayport cable products running in differentenvironments, must have on the overall product, especially for the insulating layerprotective component, which is the protective layer.

Because the requirements of insulating material has excellent variety of electrical insulation properties, must demand extremely high purity and impurity content of materials; often fail to take into account their on the outside of the protection ability,so for the outside world (i.e., installation, application occasions and in variousmechanical force) bearing or resistance, resistance to atmospheric environment,chemical resistance or oil, to prevent biological invasion, and reduce the fire hazardsmust be composed of various protective layer structure to bear. Main materials: PVC,PE, rubber, aluminum, steel strip

(6) the tensile element: the typical structure is a steel core aluminum stranded wire,fiber optic cable and cable etc.. In a word, the development of special fine, soft, alsorequires repeated bending, distorting the use of products, the tensile element plays a major role in.

Main material: steel wire

Specifications of wire and cable

The main features of the products are: different specifications, a wide range of applications, the use of voltage 1kV and below more special occasions, in the face ofconstant derived from the new products, such as refractory cable, flame-retardantcable, low smoke zero halogen / low smoke and low halogen cable, anti termite, antimouse cable, oil resistant / cold / temperature / wear cable, medical / agricultural /mining cable, thin wire etc.. With the rapid development of communication industry,from the past simple telephone and telegraph cable development to thousands of words on the cable, coaxial cable, optical cable, data cable, or even combinedcommunication scart splitter cable etc.. This kind of product structure is usually small and uniformsize, high precision manufacturing. Winding wires is a conductive metal wire insulation layer, is used for winding coil or winding of electrical products. Workthrough an electric current produces a magnetic field, or cutting magnetic line of forceto generate induction current, realize the transformation of electricity and magnetism,so it become the electromagnetic wire. Wire and cat6 cable products is the vast majority ofsection (cross-sectional) have identical shapes (ignoring the error caused by themanufacture), is a long strip shape products, this is because in the system or deviceis composed of lines or coil and used as the feature of the decision. So the study ofstructural analysis of the cable product composition, only need to observe and analyze from its cross section.

Structural element of wire and cable products, generally can be divided into wire, an insulating layer, the shielding and protecting layer of the four main structuralcomponents and the filling element and a carrier element etc.. According to the service requirements of products and applications, some products structure is very simple.

The introduction of electric wire and cable

Wires and cables used to transmit electric (magnetic) energy, information and realize electromagnetic energy conversion of wire products, wire and cable generalized also referred to as the cable, special cable refers to insulated cable, it can be defined as:aggregate is composed of the following parts; one or a plurality of insulated wire core,and their respective may have the coating layer, the total protective layer and theouter protective layer, the cable can also have additional no insulation of conductor.For the transmission of electric (magnetic) energy, information and realize electromagnetic energy conversion of wire products.

General electric wire and 21 pin scart cable is also referred to as the cable, special cable refers toinsulated cable. It can be defined as, aggregate is composed of the following parts:one or a plurality of insulated wire core, and their respective may have a coating layer, the total protective layer and the outer protective layer, the 21 pin flat scart cable can also have additional no insulation of conductor. The main features of products: pure metal conductor, no insulation and sheath layer, such as steel core aluminum stranded wire, copper bus, electric locomotive line; processing technology is the pressure processing, such as melting, rolling, drawing, stranding / pressing twist; products are mainly used in suburban, rural, user the main line, switch cabinet etc..

The types of cable conductor

Wire and cable conductor by one or a plurality of mutually insulated and outer insulation protective layer made of, will power or information transmitted from one point to another by wire. The conductor is its core, lost the conduction effect of conductor, cable will lose its value. In the copper and aluminum and other metal conductor as the representative of the "traditional forces, how to resist the" to "aluminum alloy, non fiber, carbon fiber and other new materials" representative of the "new power", it becomes more and more attractive to look forward to. At present, the metal conductor common according to the conductive arrangement, followed by gold, silver, copper, aluminum, iron (steel), but considering the application to the wire and cable connectors conductor on raw material costs and other factors, copper and aluminum are the high cost, especially copper, gold, silver, price is low, conductivity better than aluminum, is the most commonly used cable conductor. Copper conductor with the national standard cable of the oxygen free copper, electric wire and cable industry is a heavy material light industry, according to the relevant statistics show that, wires and cables with copper content of copper consumption accounted for about 60-70%. Copper conductor is a core component of copper core cable, regardless of how changes in external technology, progress, copper conductor costs can account for the total cost of cable head, reportedly as high as more than 75%. With the development of China's copper resources are depleted and the international copper prices rise, although the copper wire and crossover ethernet cable conductor is still in the "big brother", but people have begun to actively seek alternatives. Aluminum mineral resources in China is extremely rich, is one of the world's ten largest bauxite resources in the country, to maintain reserves of 25.03 tons of resources. As early as in 1957, our country has put the "Al generation copper" identified as national technology policy. In twentieth Century six, seventy time, due to copper as strategic materials subject to regulations of trade, a large number of domestic aluminium is used as the main material of conductor transmission cable. However, compared with the copper conductors, pure aluminum conductor conductor resistivity, low melting point, poor oxidation resistance, poor mechanical strength, cause problems often overheat, corrosion, short circuit and so on, in the early ninety's, he gradually withdrew from the low-voltage power distribution market, but there are still used in high voltage transmission field.

Wall-type terminals

With screw connection cable technology, insulating materials for PA66 (flammability rating: UL94, V-0), using high-quality connectors highly conductive metallic material. H-type industrial terminal block wall-type terminals can be mounted side by side on the thickness of 1mm to 10mm and other panels, panel thickness adjustment distance can automatically compensate any terminal block consisting of poles, and can be used to increase the air gap separating plate and creepage distance. No tools can be wall-type terminals securely mounted in a rectangular hole on the panel aside, the installation is extremely convenient. H-type wall-type terminals are widely used in wall solutions that require the occasion: Power, filters, electrical 12 port patch panel control cabinets and other electronic devices. Good insulation properties, high degree of protection, users only need to work directly in the external wiring, eliminating a lot of unnecessary wiring steps. Insulation material WUK series terminal with modified nylon (PA66), which can be accessed 4mm2 wire voltage of 800V electrical current is 41A connectivity products

Pluggable terminal block

Consists of two plug connection is made, a part of the cord compression, and then into the other part, which in soldered to the PCB. This pick the bottom of the mechanical principles, this anti-vibration design ensures long-term product and finished products using utp cat6 keystone jacks gas-tight connection reliability. Both ends of the socket assembly can be added to the ear, assembling in large part to protect the ear lugs and lugs arrangement can prevent poor location, but this socket design ensures proper receptacle can be inserted into the mother. Socket assembly can also have bits and locking clasp buckle bit. Buckle assembly can play a bit more firmly fixed to the PCB board, locking buckle bit can lock the mother and socket Plug-In Terminal Block after installation is complete. Socket design can be used with a variety of different maternal insertion method, for example: horizontal, vertical or inclined to the printed circuit board, you can choose different ways according to customer requirements. You can select either metric gauge can also choose standard gauge, is terminal block type on the market selling.

the history and definition of terminal block

1928, Phoenix Electric invented the world's first one modular terminal block, which is the prototype industrial terminal block of the modern terminal is Phoenix Electric applied for and obtained the first patent. Since then, Phoenix Electrical passion innovation, commitment to the development of various connection technologies, forming a perfect electrical interface technology systems, many of which product series has become the industry standard application. To 2012, CLIPLINE product range has more than 3000 kinds, widely used in various industrial control cabinets and electrical connection cabinet occasion. terminal block 12 port patch panel is to facilitate the application of the wire connection, it is actually a period of closure in insulating plastic inside the metal sheet has holes at both ends of the wire can be inserted with screws for fastening or loosening, such as two wires, sometimes need to be connected, and sometimes you need to disconnect, then you can use the terminal to connect them, and you can cate5e network cable disconnect at any time, without having to weld them together or intertwined, it is quick and easy. And for a lot of wire interconnect in the power industry have a special terminal block, terminal box, above all terminals, a single layer, double layer, current, voltage, common, can be broken, and so on. A crimp in order to ensure reliable contact with the area, and to ensure a sufficient current through.

Terminals requirements

Mechanical structural safety requirements terminals in terms of chemistry and structural materials and moving parts to ensure the safety of live, such as shell edges, hardware aspects of glitches, and various parts of the connection strength, even stable under electrical terminal block exercise conditions sex, above all in the mechanical structure of the power industry requirements for terminals.
2, enclosure protection requirements mainly JB / T 9568-2000 provides for protection class, it is mainly divided into two types, one is solid foreign protection level, one is water damage caused to equipment and products.
3, insulation coordination requirements are mainly based on the materials used, the working voltage and environmental pollution levels, come together to select clearances and creepage distances, thereby protecting the safety of staff and products work, but also make the product does not occur in the over-voltage insulation damage .
4, the tracking index requirement for the product in the course of the surface of the solid insulating materials in the electric field and an electrolyte to form a conductive path, so that the insulating properties of the insulating material housing decline, affecting the safety of the product. If insulation voltage level at the same conditions, tracking index is high, the product creepage distance can be reduced, if the product enters power sector development in this regard, please pay full attention.
5, the thermoplastic material in the work requirements of the deformation, which is mainly of the temperature and the contact resistance of the terminals in the work, the high temperature which causes the deformation of the housing becomes soft, so that the electrical short-circuit, resulting in a serious accident, so the carrier terminals Select the material flow components was very important.
6, electric shock requirements, the structural aspects of the operating element should not be charged, terminal and internal PCB Spring Terminal Block connections should be accessible to this area mainly for screw torque and reliability requirements, should prevent the screw terminals can be touched, Loose wires accidentally shorted. Such as the ground terminal requirements: ground resistance class security products should not exceed 0.5Ω.

Wiring terminals FAQ

1, deformation stitching portfolio digit growth, the main reason is because of the irrational structure of the Falcon lead to the uneven stitching two up and down in front, as shown in the structural design must consider the force and deformation of its splicing Falcon direction. 2, screw anti-out problem, in this regard, I recommend the best Barrier terminal block use of anti neck out, because it is compared with the hoop off avoids anti-mouth screw rod and hoop mouth tolerances annoyance. And reliable construction tolerances easy to control. 3, screws and steel pieces with salt spray test in question after plating, due to the company by 2012 standard thread plating (plating is limited, but much of the thread corresponding coating thickness I think remains to be determined), to solve this problem There are two ways in the plating process under normal circumstances, to choose the right sealer and use of the coating in multiple plating, these two methods are to be covered with the naked eye can not see the screw voids generated. Coating a plurality of times using high cost of electroplating, it is recommended to use the first method, this method is that the key is to study the Plug-in terminal block sealer formulation. 4, insertion force the issue in this regard relates to the content more, it has a relationship with the material, plating, structure and industry applications, the connector industry is an important mechanical performance requirements, plug-in terminal even more so, the choice of materials is limited by the terms of the insertion force conductivity (current) and contact resistance and temperature rise. Here is not to do a detailed description of the plating is mainly affected by the type of coating and plating of whether pre-impact, Generally speaking, in the same material and structure than the first pre-plated compression tableting press and then plated plug power in regard to stability, because after the plating process is the invisible material made of hardened metal , and just prior to pressing to eliminate this phenomenon. The main consideration is the structure of the contact pressure plate and lead the needle, needle and tablet lead exposure, mostly in line contact, which resulted in an instant when suddenly appeared with a big plug, and then suddenly smaller, to customers in process used in a very unstable feeling, affecting their life, if the contact pressure plate and lead the needle into surface contact structure, then not only solve the problem of insertion force and reduces contact resistance and temperature l.

Wall type terminal block

With screw connection cable technology, insulating materials for PA66 (flammability rating: UL94, V-0), using high-quality connectors highly conductive metallic material. H-type wall-type terminals can be mounted side by side on the thickness of 1mm to 10mm and other Barrier terminal block panels, panel thickness adjustment distance can automatically compensate any terminal block consisting of poles, and can be used to increase the air gap separating plate and creepage distance. No tools can be wall-type terminals securely mounted in a rectangular hole on the panel aside, the installation is extremely convenient. H-type terminal block wall is widely used in some of the solutions that need to pass through the wall of the occasion: Power, filters, electrical control cabinets and other electronic devices. Good plug in terminal block insulation properties, high degree of protection, users only need to work directly in the external wiring, eliminating a lot of unnecessary wiring steps. Insulation material WUK series terminal with modified nylon (PA66), which can be accessed 4mm2 wire voltage of 800V electrical current is 41A connectivity products

What is the male and female terminal block and standard terminal block?

Female terminal block and the male terminal block: the female terminal or the male terminal of the material to the copper alloy, copper alloy or plating, nickel, or nickel alloy. Forming the female terminal or the male terminal has been trimmed in the form of plug in terminal block strips, if, when the terminal with the processing tool continuously into the terminal and the terminal will be crimped and with separate, then in this case, terminals, and contact with the edge of the terminal plating is not required. Standard Terminal: The mechanical properties of the test, plug in terminal block test insertion - pull out the material standard terminals used in the test should be non-plated brass, equivalent to the standard terminal C26000 alloy at temperatures and thermal cycling tests used should be resistant to corrosion spring terminal block or tin plate steel, by standard Rockwell 30T hardness, Rockwell hardness of 68 ± 5. Only if the female terminals connected to a copper alloy male terminal, then when you need to use a standard terminal standard C26000 copper alloy terminal 30T Rockwell hardness test according to the standard, made of brass a hardness of 62 ± 7

What is a plug-in terminal block?

Pluggable terminal block, consists of two plug connection is made, a part of the cord compression, and then into the other part, which in soldered to the PCB. This pick the bottom of the mechanical principles, this anti-vibration design ensures long-term product and finished products using gas-tight connection reliability. Both ends of the socket assembly can be added to the ear, assembling in large part to protect the ear lugs and lugs arrangement can prevent poor location, but this socket design plug in terminal block ensures proper receptacle can be inserted into the mother. Socket assembly can also have bits and locking clasp buckle bit. Buckle assembly can play a bit more firmly fixed to the PCB board, locking buckle bit can lock the mother and socket after installation is complete. Socket design can be used screw terminal block with a variety of different maternal insertion method, for example: horizontal, vertical or inclined to the printed circuit board, you can choose different ways according to customer requirements. You can select either metric gauge can also choose standard gauge, is terminal block type on the market selling.

terminal block classification

terminal block can be divided into WUK terminals, Continental Connection series, pluggable terminal block series, transformer terminals, building wiring terminals, Barrier Terminal Block Series, spring-type terminal block plug series, rail-mounted terminal block series, wall terminal Blocks series terminal block series optocouplers, 110 terminals, 205 terminals, 250 terminals, 187 terminals, OD2.2 ring terminals, 2.5 ring terminals, ring terminals 3.2, 4.2 ring terminals, two ring terminals , 6.4 ring terminals, 8.4 ring terminals, 11 ring terminals, 13 terminals flag series ring terminals and jacket series, all kinds of ring terminal, tube-shaped terminal, Barrier terminal block, copper iron band (2-03, 4-03,4-04,6-03,6-04) and the like.

What is a terminal block?

terminal block is to facilitate the application of the wire connection, it is actually a period of closure in insulating plastic inside the metal sheet has holes at both ends of the wire can be inserted with screws for fastening or loosening, such as two wires, sometimes need to be connected, and sometimes you need to disconnect, then you can use the terminal block to connect them, and you can disconnect at any time, without having to weld them together or intertwined, it is quick and easy. And for a lot of wire interconnect in the power industry have a special terminal block plug, terminal box, above all terminal block, single-layer, double layer, current, voltage, common, can be broken, and so on. A crimp in order to ensure reliable contact with the area, and to ensure a sufficient current through.screw terminal block is used to achieve an electrical connection accessories products, divided into categories on the connector industry. With the increasingly high degree of industrial automation and industrial control requirements more stringent, precise, electrical terminal block dosage gradually rise. With the development of the electronics industry, terminal block the use of more and more, and more and more types. Currently the most widely used in addition to the PCB terminals, there are hardware terminals, nuts terminal, spring terminal, and so on. Historical development editor in 1928, Phoenix Electric invented the world's first one modular terminal block, which is the prototype of the modern terminal is Phoenix Electric applied for and obtained the first patent. Since then, Phoenix Electrical passion innovation, commitment to the development of various connection technologies, forming a perfect electrical interface technology systems, many of which product series has become the industry standard application. To 2012, CLIPLINE product range has more than 3000 kinds, widely used in various industrial control cabinets and electrical connection cabinet occasion.

Widely used Barrier Terminal Blocks

Barrier terminal block for electrical and electronic engineering industry:
lighting, elevator control, instrumentation, electrical, chemical and automotive power supplies. For their safety, reliable and efficient connectivity,while electrical terminal block widespread use under high current, high-pressure environment. There are two basic types of terminal block: UL and IEC. UL standard rated voltage and rated current is 300V, 15A, and in accordance with IEC standard electrical performance is 250V, 24A.
Blocking the spring terminal block is typically within 7.6 mm pitch and the number of poles for 2~26P range. Barrier terminals are mostly made ​​of brass, is locked to the maximum torque of the torque due to the mechanical properties of the barrier terminal 0.54.4Lb.in. materials and measurements, which can be applied at a maximum temperature of 105 ℃, the lowest temperature is -40 ℃. All of the features that make the barrier terminal blocks access to a huge market prospects.

plug in terminal block configuration

plug in terminal block consists of two parts connected by plug part of the cable clamp, and then into the other part, which in soldered to the PCB board. This connector at the bottom of mechanical principles,electrical terminal block this anti-vibration design ensures long-term product and finished products using gas-tight connection reliability. Both ends of the socket assembly can be added ears, assembling in large part to protect the ear tabs and tab arrangement can prevent poor location, but this outletplug in terminal block is designed to ensure that the socket can be inserted into the correct parent. Socket assembly can also have bits and locking clasp buckle bit. Buckle assembly can play a bit more firmly fixed to the PCB, the lock button to lock the mother and socket bit after the installation is complete. Socket design can be used with a variety of different maternal insertion method, for example: horizontal, vertical or tilted to the printed circuit board, you can choose a different way according to customer requirements. You can select either metric can also choose standard gauge AWG, terminal type on the market is selling.

terminal blocks labeling method

 Same element group, before the number preceded by the letter, if not necessary to distinguish phase, available digital-5N, -2.5, -16 mark.
 Same set of components. With a specific electrical wire terminals connected to a sign. The pressing means is the terminal blocks between the conductor and the conductive body of the pressure generated only generate sufficient pressure to ensure a low contact resistance, a good connection is formed, the reliability of the pressing machine is connected directly to the wire impact good or bad. Speaking of screw-type plug in terminal block screws, studs and are important components platen clamping mechanism; screwless terminals for speaking, spring or spring card is an integral part of the compactor. No screw-type spring terminal block ,clamping mechanism is mainly spring, so crucial to the selection of the spring, it is necessary to ensure that there is sufficient contact pressure to ensure that not too much damage to the wire,PCB Spring Terminal Block is more reliable screwless terminals. When the line, you can block or suppress the spring by pushing a screwdriver, into the line, release the spring, the spring tension back pressed firmly to the wire, resulting in sufficient contact pressure, and then strangled with a spring wire cutting edge, so it does not pull out loose or man-made.
 Each terminal in the middle of said single element in a natural number incremented sequence number.

The anvantages of wisdom barrier terminal block

Wisdom barrier terminal block is able to achieve safe, reliable and efficient connectivity, especially in high current, high voltage enviro?nment used widely. Terminal Features Use of the existing rail-mounted terminal transmission coupling terminal WUK connection technology, and the installation of a circuit composed of electronic components, to achieve the photovoltaic process.
Automatic control is the core of the control unit must be with the sensors and actuators reliably isolate avoid interference,three Bay WUKG2 light across terminal block plug could achieve this function, and to ensure that on-site signal and electronic control devices required for low voltage matches the interface between the peripheral device and the device control signal and adjusting means can be used for further process control, and is suitable for different voltage and power range.
Under the control of light across the electrical terminal block have terminal signal loss, high switching frequency, jitter no mechanical contact, no wear switch, high voltage insulation, are not afraid of vibration, without affecting the position and long life and other advantages, so widely used in the field of automatic control.

Barrier Terminal Block national standard identification methods to identify

One or more of the following may be used to identify a particular device barrier terminal block and 24 port patch panel terminals.

A related product labeling system uses to determine the actual or relative location and identification device terminals or specific wire line side.

2 related products using the tagging system to identify and recognize the device terminals and specific color-coded wire terminals.

3 using graphic symbols specified in crossover ethernet cable‍  For the use of auxiliary symbols, should be consistent with the GB4728 graphics.

4 uses specified in Chapter 5 of this standard alphanumeric symbols.‍

Barrier Terminal Block national identification standards subject matter and scope

This standard Cat5e keystone jack‍ a variety of methods to identify electrical equipment (hereinafter referred to as device) barrier terminal block, and developed a system to identify equipment alphanumeric terminals and specific wire line side of General.

This standard applies to the identification vga extension cable‍ of the combination of the terminal equipment (such as resistors, fuses, relays, contactors, transformers, rotary motors, etc.), and these devices, but also to identify the specific wire line side.

If necessary, these can be given to the General detailed application of certain products and the necessary supporting identification method in the relevant standard.‍

Manufacturing principles plug terminals

plug in terminal block wiring terminals manufacturing principles: we open generic computer disk will be able to see a health flexible film (flexible insulating substrate), there are printed on the rj11 modular jack‍ (silver) conductive pattern and healthy position graphics. Because Universal serigraphy method to get this graphic, we call this a flexible printed circuit boards for the Silver PCB. The printed circuit board computer city we went to see the variety of computer motherboards, graphics cards, network cards, modems, 3d HDMI cable‍ cards and household appliances on different. It is used by the paper-based substrate (commonly used in single-sided) or glass cloth (commonly used in double-sided and multilayer), phenolic or epoxy prepreg, surface glue on one side or both sides of the copper-clad laminate curing book again made. This circuit board copper book plate, we call it a rigid plate. Then made PCB, we call it a rigid printed circuit boards.

Plug Terminals PCB manufacturing principles of interpretation of a single negative

There are single-sided printed circuit pattern we said PCB, double-sided printed circuit pattern, and then double-sided printed wiring board formed by metallization rj45 ethernet connector‍ holes, we called double panel. If you use a double-sided for the inner, two-sided or two-sided as to make the outer lining, two-sided printed circuit boards for the outer layer, through the positioning system and insulation material are alternately bonded together and terminal block plug‍ pattern according to the design requirements for the interconnection of printed circuit boards become four, six of the printed circuit board, also known as multi-layer printed circuit boards. Now more than 100 layers of practical printing plug in terminal block up.

terminal block alliance is built on the memory of the network model of cognitive psychology

China terminal block to join the brand is built on the memory of the network model of cognitive psychology. Cognitive psychology that rj45 magnetic jack memory is like a network with many cat6 cable as these nodes have some connection with the relevant contact. Each node is a memory cell, the memory is used to express a fixed point of each piece of information, such as a concept, or a range. A product category, product name or product properties can be regarded as a consumer node memory. Memory of each node has its specific name, such as product name, product type names, product attribute names and so on.

Introduction terminal block Union

Member companies can work together to carry out in-depth dialogue with the major industry B2B e-commerce online trading platform to explore such as "2010, the voice patch panel‍ industry dark horse who is? Terminals Chinese market will go from here," and so on society, business and brand issues, the Union of its member companies do not charge 21 pin flat scart cable‍ fees, six members of the meeting planned to be held annually, each operated by a group led by the regional companies. "Nanjing Sanmen Bay Electric Co., Ltd." will serve as the secretariat alliance to provide support for daily activities alliance.

terminal block of the Union

For domestic enterprises to provide electrical company presentations, electrical product releases, product Wanted, technology exchange and other services.

July 1, 2010, "China Enterprise Alliance Terminal" in Nanjing was officially established.

The terminal block co-sponsored by the rj45 ethernet jack‍ of Jiangsu, Zhejiang, Shanghai and the Pearl River Delta and many other brands, there are 130 enterprises have become the league's first zone member companies.

"China Enterprise Alliance Terminal" to take USB extension cable‍ voluntary, independent, autonomous joining communication, aims to provide a platform for sharing experiences and resources with sustainable development goals for the company, by way of exchanges and cooperation in this area or bring greater social and economic benefits.‍

Test Block Barrier terminals

Switch from the role of sliding metal HDMI DVI cable‍ through the terminal can withstand the maximum pressure operating current, loosen the screws with a screwdriver when switching, move the slider on the line, switch positions glance; its cat5e network cable‍ with a test socket, equipped with the appropriate test ends can be connected to test, measure the current operation without interruption. Can be connected to 660V voltage control loop current is 57A.

Insulation material fence terminals

Modified nylon insulating material with good electrical properties and mechanical properties. Screws of high strength copper alloy, a conductive body formed with copper, the pressure frame with the resistance to vga extension cable‍ crack corrosion of copper alloys, the metals tin or nickel plated surface is also protected. Copper battery terminals to avoid the effect of steel metal parts and copper wire in wet environments. There are intermediate terminal connection hole can also be used to connect the center edge plug-in connecting piece; ftp cat5e keystone jack‍ wires can be connected to 800V current 41A voltage electrical products.

The definition of terminal block

Terminal is used to achieve a accessories electrical connection, the pcb spring terminal block connector into the scope of the industry. With the increasingly high level of industrial automation and industrial control requirements become more stringent, precise, terminal blocks dosage gradually rise. With the development of the electronics industry, the use of the terminal more and more, and more and more types. Currently the most widely barrier terminal block used in addition to the PCB terminal, there are hardware terminals, screw terminals, spring terminals, etc., in the power industry have a special terminal block, terminal box, above all terminals, monolayer, bilayer , current, voltage, ordinary, and the like can be broken.

The definition of terminal block

Terminals and applications in order to facilitate wire connection, it is actually inside some enclosed in insulating plastic sheet metal, wire can be inserted into the hole at each end, for tightening or rca video cable screws, such as two wires, sometimes need to be connected, and sometimes you need to disconnect, then you can use the terminal to connect them, and you can disconnect at any time, without having to weld them together or intertwined, it is quick and easy. And is suitable for a large number of interconnected wires in the power industry have a RJ45 PCB jack terminal block, terminal box, above all terminal blocks, single and double, current, voltage, ordinary, can be broken and so on. A crimp in order to ensure reliable contact with the area, and to ensure a sufficient current through.

The historical development of terminal block

In 1928, Phoenix invented the world's first one modular terminal block, which is the prototype of the modern terminal is Phoenix applied for and obtained the first patent. Since then, dvi adapter passion and innovation, committed to the development of a variety of connectivity technologies, forming a perfect electrical interface technology system, many products have become the industry standard application. Currently, hdmi extension cable product range has more than 3000 kinds, widely used in various industrial control cabinets and electrical connection cabinet occasion.

terminal block

Terminal is used to achieve a accessories electrical connection, the connector into the scope of the industry. With the increasingly high level of industrial automation and industrial vga cable requirements become more stringent, precise, terminal blocks dosage gradually rise. With the development of the electronics industry, the use of the terminal more and more, and more and more types. Currently the most widely used in addition to the Mini HDMI cable terminal, there are hardware terminals, screw terminals, spring terminals, etc., in the power industry have a special terminal block, terminal box, above all terminals, monolayer, bilayer , current, voltage, ordinary, and the like can be broken.
